- Maximum Intermittent Pressure = 5000psi
- Maximum Continuous Pressure = 3000psi
- Maximum Differential per Section = 3000psi
- #10 SAE Outlet Ports (O-ring)
- #10 SAE Inlet Ports (O-ring)
- #16 SAE Inlet Ports on each end (O-ring)
- Built-in relief valve
Product Description
|
Gibson Model FL Flow Divider
11000000 11100000 11110000 11111000 11111100 33000000 33300000 33330000 33333000 33333300 55000000 55500000 55550000 55555000 55555500 77000000 77700000 77770000 77777000 77777700 |
O. P. S. I. displacement per section
0.00317 0.00317 0.00317 0.00317 0.00317 0.00476 0.00476 0.00476 0.00476 0.00476 0.00634 0.00634 0.00634 0.00634 0.00634 0.00793 0.00793 0.00793 0.00793 0.00793 |
Number of sections
2 3 4 5 6 2 3 4 5 6 2 3 4 5 6 2 3 4 5 6 |
Minimum Inlet in GPM
4.6 6.9 9.2 11.5 13.8 7.2 10.8 14.4 18 21.6 9.2 12.8 18.4 23 27.6 11.8 17.7 23.6 29.5 |
Maximum Inlet in GPM
19 28.5 38 47.5 57 28.6 42.9 57.2 71.5 85.8 38 57 76 95 114 48 72 96 120 |
