HF 410 and HF 412 suction line filters offer a flow up to 80 US gpm (300 l/min) and connect directly to the hydraulic circuit suction line to protect components against contaminant particles. By-pass valves are available set at 2.9 psi (0,2 bar). Operating temperature = -22 195 °F (-30 90 °C). Versions with oversized filtering surfaces are available and denoted by “FS” in the part number.
- Head made of reinforced nylon
- End cap made of zinc plated steel
- Inner tube made of zinc plated steel
- Filter media made of steel wire mesh or stainless steel wire mesh
Product Description
Fluid Compatibility:
- Conforms to ISO 2943 (Norm ISO 6743/4)
- Mineral oil:
- HH
- HL
- HM
- HR
- HV
- HG
- Water emulsion:
- HFAE
- HFAS
- Water glycol:
- HFC
- Synthetic fluid:
- HS
- HFDR
- HFDU
- HFDS
Degree of Filtration
- MI025 Stainless steel wire mesh 25μm
- MI060 Stainless steel wire mesh 60μm
- MS090 Steel wire mesh 90μm
- MI125 Stainless steel wire mesh 125μm
- MI250 Stainless steel wire mesh 250μm
