Supplies flows to multiple circuits with a common supply, or for combining flows into a common line. Flow from port 3 is divided equally between port 1 and port 2 within the flow tolerance. Flows from port 1 and port 2 are combined into port 3 within the flow tolerance -08 SAE gage port 4.
Product Description
- Aluminum body, steel internals
- Pressure compensated
- Hydraulic fluids – general.
- Buna-n 90 duro o-rings
- Tamper resistant
- Technical Specs:
- Pressure range: 250 psi to 4500 psi
- Temperature range: 250°f to -40°f
- Flow tolerance: +/- 10%
- Max. Pressure differential: “1” to “2” – 100 psi
- Divide / combine ratio: 50:50
