- Flows: Up to 96 GPM on the return line and 32 GPM on the suction line
- Port Sizes:
- 1 1/4″ & 1 1/2″ NPTF
- 1 5/8″ – 12 (SAE – 20)
- 1 7/8″ – 12 (SAE – 24)
- 1″ & 1 1/4″ BSP
- Maximum operating pressure by model:
- RF model – 100 PSI
- WF model – 500 PSI
- Up to 250° F operating temperature
- For use with petroleum based fluids
Product Description
Zinga RF and WF tank top filters use the following RE cellulose and ZRE synthetic filter elements in 3, 10, 25, & 141 micron filtration.
- RE-409-03
- RE-409-03AZ
- RE-409-10
- RE-409-10AZ
- RE-409-25
- RE-418-03
- RE-418-10
- RE-418-25
- RE-409-100
- RE-409-100R
- RE-409-100M
- RE-409-100MR
- ZRE-409-03
- ZRE-409-03R
- ZRE-409-10
- ZRE-409-10R
- ZRE-418-03
- ZRE-418-03R
- ZRE-418-10
- ZRE-418-10R
