A great choice for agricultural and industrial uses, as this remote control flow divider is vibration and contamination resistant and can be powered from a vehicle supply using the on-board 9 – 28 V D.C. supply. Current draw is automatically limited to avoid overheating or motor overload. Model FDM offers a low-cost method of controlling the speed of a hydraulic motor. The regulated (priority) flow port gives an output free of affect by load pressure while the bypass port can be directed to power a secondary hydraulic circuit. Remote control use from up to 130 feet is possible using a potentiometer.
Product Description
- Designed to meet Nema type 5
- Flow Ranges: 0.15 – 3 gpm, 0.15 – 5 gpm, 0.15 – 8 gpm, 0.15 -12.5 gpm, 0.15 – 20 gpm, 0.15 – 25 gpm, 0.15 -30 gpm
- Maximum Pressure: 3600 psi
- Port Threads Inlet Regulated Flow and Excess Flow: 3/4” BSPP, 3/4” NPTF, M22 x 1.5, M27 x 2, 1-1/16” -12UN #12 SAE ORB, 1/2” BSPP
- Also available in a Manifold Mounted Variable Priority Flow Divider
