By combining IPVS pumps with other Voith medium-pressure and low-pressure gear pumps to create dual-flow or multi-flow pumps.
Product Description
Model Numbers:
- IPVS 3 – 3.5
- IPVS 3 – 5
- IPVS 3 – 6.3
- IPVS 3 – 8
- IPVS 3 – 10
- IPVS 4 – 13
- IPVS 4 – 16
- IPVS 4 – 20
- IPVS 4 – 25
- IPVS 4 – 32
- IPVS 5 – 32
- IPVS 5 – 40
- IPVS 5 – 50
- IPVS 5 – 64
- IPVS 6 – 64
- IPVS 6 – 80
- IPVS 6 – 100
- IPVS 6 – 125
- IPVS 7 – 125
- IPVS 7 – 160
- IPVS 7 – 200
- IPVS 7 – 250
- 1) Pinion shaft
- 2) Internal gear
- 3) Filler pin
- 4a) Filler segment carrier
- 4b) Filler sealing segment
- 5) Axial disc
- 6) Axial pressure area
- 7) Plain bearings
- 8) Housing
- 9) Hydrostatic bearing
- 10) End cover
- Yellow = Suction Chamber
- Orange = Pressure Chamber
